The vacuum cleaner cleaning performance test bench is manufactured according to GB/T20291.1-2014 \ I60312-2010 IEC62885-2-2020 and other relevant standards, mainly for the dust removal capability test vacuum cleaners on carpets and floors. The equipment is controlled by PLC and driven by servo mechanism to simulate the actual use conditions of vacuum cleaners on test carpets/flo for comprehensive evaluation tests of dust removal capability test/cleaning capability test. The equipment drives the tested vacuum cleaner at a adjustable speed of 0-1M/s through P related settings and controls, and performs reciprocating dust removal on the test floor/carpet.

    During the test, the system collects relevant voltage, current, power electricity and other parameters, and records relevant test data. Relevant test data can be exported via USB and printed. It is widely applicable to vacuum cleaner manufacturers and testing institutions in cleaning industry for dust removal and vacuum cleaner cleaning capability testing. Carpet dust removal, wooden floor dust removal, groove gap dust removal, data collection and processing software. Vacuum cleaner equipment, vacuum cleaner dust removal capability test equipment, dust removal performance testing equipment IEC 62885-1:2016 "Surface cleaning equipment Part : Domestic dry vacuum cleaner Test method" Clause 7 (Dust removal performance test) GB/T 20291.1-2021 "estic vacuum cleaner Part 1: Dry vacuum cleaner Performance test method".
