The test items include performance test, energy efficiency test, voltage test, flow test, temperature test, power and energy consumption test, etc.

Meet the requirements of chapter 18 of GB4706.1 and GB4706.12 -2006 special requirements for safe storage water heaters for household and similar electrical appliances

GB 21519-2008 storage type electric water heater energy efficiency limit value and energy efficiency level requirements, using PLC Industrial Control Computer Control, it can program the project, detect the process automatically, track and collect the data, distinguish and classify the conclusion, store the data automatically, and make it easy to find, analyze, count and print

Main technical parameters:

 1, station number: 2 -10 stations optional, each station independent monitoring.

2.There are two water supply pipelines: one is water supply pipeline and the other is pressurization pipeline.

3.Using stainless steel 304 pipeline

4.Temperature range: 5-85 ° C precision: 0.25 grade

5.Control mode: Industrial Control Computer Main Control, remote cooperation function

6.Pressure parameter: range 0.07 MPA, minimum scale 0.01 MPA.

7.Flow parameter: range 0.1-100L/MIN

8, equipment power supply 220V, 30KVA/optional external inverter power

9, equipment size: 2200X 1200x 1650 units: MM

10, other functions: 4G/5G remote control, detect Data USB export
