The equipment is used to realize the automatic aging test of the induction cooker. Each set of machine structure is designed with 2 layers

 and 8 stations. PLC automatic control and detection, computer monitoring and recording, automatic switch and water, overtemperature

 automatic pause, can realize unattended automatic aging, can greatly improve work efficiency, reduce test operation safety hazards, improve

the detection speed and data accuracy.

Technical parameters:

1、single machine reference outline size: 2000x 600x 1700mm (length x width x height)

2、Test Station: 8 Station

3、output socket: Single Station Maximum Output Current 15A

4、use power supply: three-phase four-wire with ground wire supply AC380V + 10% 50Hz.

5、Timer Range: 0-999999 S MH can be set

6、digital display output: 0-300V 0-250a

7、Automatic Water Adding Device

8、control mode: Mitsubishi PLC + 7-inch Display Display Display

9、 Data Export: USB
