1. Inspection stations: 18 stations (customized according to customer requirements)

2. Detection functions: current, voltage, power, on-off time, operation time, etc

3. Set the number of tests, duration, and upper and lower limits for current alarms, with independent display and judgment for each workstation;

4. Equipped with smoke alarm, audible and visual alarm, and automatic power-off function

5. It has a two-tier structure, with 6 products clamped on each tier,

6. Judgment method: current upper and lower limits

7. Equipped with a high-temperature exhaust system on the top

8. Equipped with a leakage protection switch and overcurrent and overvoltage protection devices.

9. Voltage: 0--250V, detection current: 0-30A, adjustable

10. Control mode: 17-inch touch screen + industrial computer display (MES system transmission -- optional)

11. Weight: approximately 650Kg,

12. Power Supply: 220V 3.5KW. Sample Power Supply - External

13. Equipment dimensions: 1800 x 750 x 1750 mm
