1. Introduction   IPX8 immersion test chamber,The IP Waterproof Grade Test Machine is designed and manufactured in accordance with the requirements of GB4208-008 "

Shell Protection Grade (IP Code)" standard. This equipment is widely used in lighting products, electrical and electronic, military products, certification testing institutions, and quality control of production enterprises for

 the IPX7 and IPX8 waterproof grade testing of products.

 2. Main Technical Parameters:

1. Interior size of the box: D00×H1000mm. (The size is designed according to the customer's sample)

2. Equipment structure: 304 stainless steel water, with a scale-marked organic glass view window in front of the water tank.

3. Level control: Float switch

4. Scale length: 1000, accuracy 1mm.

5. The box body is reinforced with stainless steel square tubes.

6. Pressure regulation range: 0～2.5Mpa. Sim water depth: 0-250M

7. Pressurization system: Stainless steel water pump   frequency converter.

8. Pressure gauge accuracy 025 grade, range 1.6Mpa.

9. Test time: 0-9999min.

10. Maximum limit pressure: .5Mpa.

11. Pressure protection: Pressure switch protection.

12. Control mode: Mechanical / Mitsubishi PLC control

13. Pressure drive: Air pressure / water pressure

14. Power supply: 220V 3.5KW
