Quick connector high and low pressure sealing testing equipment,The high and low pressure sealing testing equipment for quick connectors is commonly used for multi specification quick connector male and female products. Through program control, it completes low pressure sealing testing and high pressure sealing testing; We can customize according to customer requirements, and the internal detection module adopts our company's independently developed leak detector. The test bench adopts PLC main control and touch screen Chinese display operation; Using pneumatic principles to quickly clamp the product, wear-resistant silicone is used as the sealing element, and high-precision pressure transmitters are used to detect the constant pressure and fluctuations inside the product. Equipped with automatic judgment and alarm functions. OK - Qualified, NG - Unqualified with audible and visual alarm;Quick connector high and low pressure sealing testing equipment

Scope of application: Production line sealing testing, laboratory sealing testing, and other general industries. Non standard customization can be carried out based on customer samples and relevant requirements.

1、 Overview:

The four station airtightness testing equipment combines airtightness testing with automated testing; We can customize according to customer requirements, and the internal detection module adopts our company's independently developed leak detector. The test bench adopts PLC main control and touch screen Chinese display operation; Using pneumatic principles to quickly clamp the product, wear-resistant silicone is used as the sealing element, and high-precision pressure transmitters are used to detect the constant pressure and fluctuations inside the product. Equipped with automatic judgment and alarm functions.Quick connector high and low pressure sealing testing equipment

OK - Qualified, NG - Unqualified with audible and visual alarm;

The system operation is simple, and the accessories used are imported and well-known domestic brands, ensuring stable and reliable operation.

Scope of application: Production line sealing testing, laboratory sealing testing, and other general industries. Non standard customization can be carried out based on customer samples and relevant requirements.

2、 Technical parameters:

1. Number of workstations: Four workstations (up to 8 workstations can be customized)

2. Pressure test range: 0.01-0.6Mpa, test pressure accuracy: 0.1 level/0.25 level/0.5 level

3. Pressure holding time: 1s-99999S adjustable

4. Pressure method: 01: direct pressure 02: differential pressure 03: vacuum type

5. Control mode: 7-inch touch screen/PLC control

6. Using single-phase power supply with ground wire: AC220V ± 10%, 50Hz 1.5KW

7. Equipment size: 300 X 420 X 250 Unit: MM
