1. According to the JBT/T 3259-1991 and JBT/T 9584-1999 standards and relevant industry testing standards, the performance testing platform for electric plugs is designed to withstand customer testing requirements. Real time collection of energy parameters such as current, temperature, and operating time through PLC. Apply electric heating/blowing forced cooling cycle life test to the electric heating plug with adjustable current of 0-70A, record the temperature time and current value changes of the indicators, and generate relevant test curves. The relevant test data system automatically saves and can export data through USB.

2. The detection and control system is controlled by a PLC platform and displayed on a 17 inch industrial touch screen. Adopting touch display, each workstation product has independent power supply, independent temperature collection, independent timing, and independent strong wind cooling. The relevant test data and curves are displayed independently.

2、 Related testing process:

Using high-temperature resistant materials to horizontally clamp the tested electric plug, connect the power supply line, adjust the position of the infrared temperature probe, set the relevant test parameters on the touch screen, adjust the tested voltage and current, start the test, record the relevant current, temperature, and time in real time, generate a curve in real time, test one cycle, start the compressed air to cool the workstation product, complete the test, unload the material, automatically save the data, and export via USB.
