The thermistor resistance central control system is mainly used for online detection on the production line. It is suitable for online resistance judgment online screening test of thermistor resistance. The thermistor test is detected through our company's independently developed resistance central control system, and the 17-inch industrial computer displays data in real time and has functions such as automatic data saving and data export. The temperature controller test equipment central control system is divided into 9 channels, each channel has 4 gears, and each gear is divided into two groups of indicator lights. There are 80 indicator lights in total, of which 40 indicator lights are used for marking on resistance sorting bucket. The central control system has 9 channels, each channel is an independent detection. The central control system uses a 40X40 aluminum profile structure for, Japanese Mitsubishi PLC control and 17-inch touch screen display. The control mode is manual and automatic. The test ends and the fault alarm automatically pauses, can realize unmanned full-automatic aging, greatly improve work efficiency, reduce test operation safety hazards, and improve detection speed and data accuracy.

Operation process: Thermistor test   Temperature controller test equipment, each workstation operator manually clamps the thermistor product through the pressure plate fixture-------The workpiece fixture with the product installed is in the oil tank through the quick plug fixture-----The workpiece is fixed through the fixed fixture-----The temperature and resistance are monitored by the computer----The temperature reaches set value-----The system automatically collects the relevant resistance value-------Calculate and compare through the system----The resistance value is classified-------The system automatically turns the calculation and control of the relevant resistance value indicator light----Prompt through the control of the corresponding resistance gear indicator light and the sorter indicator light-------The operator sorts and places it in the corresponding sorter bucket interior----Complete----Repeat the above actions.
