The GB31241 battery forced discharge test device is a specialized equipment for testing single cells or battery packs of lithium-ion batteries used in portable electronic devices. It is designed and manufactured for PSE certification according to the testing requirements of clause 5.5 of the Japanese Industrial Standard JISC8714:2007. It is designed and manufactured for PSE certification according to the testing requirements of clause 5.5 of the Japanese Industrial Standard JISC8714:2007.

Temperature control: high and low temperature test chamber

1. Outer box material: Cold rolled sheet with rust prevention treatment and spray coating.

2. Inner box material: Made of 304 stainless steel.

3. Internal dimensions of the test chamber: 600 × W500 × D400 mm.

4. Temperature control range: 10-60 ° C, uniformity ± 2 ° C.

5. It has fire prevention and exhaust functions (exhaust gas after the test is completed) and a fire observation window.

6. There are four universal casters at the bottom of the box, and one lighting fixture is equipped inside the box.

7. A 50mm test lead hole on the left side of the box

8. Temperature controller: Intelligent temperature controller, temperature control adopts P.I.D+S.R.R, system synchronous and coordinated control, which can improve the stability and service life of control components and interfaces; The digital temperature direct reading has the function of P.I.D automatic reading and calculation, which can reduce the error caused by manual setting; Provide warning signals in case of errors during setup or operation.
