This machine is used to simulate the riding environment test of bicycles or electric bicycles. The assembled finished vehicle is placed on the machine, the weights are fixed according to the standards, the safety devices are adjusted, and the relevant parameters are set on the microcomputer. After that, the computer automatically executes the test.

Compliant with standards: Made in accordance with the requirements of GB/17761-2018, ASTM2641-2008, GB 3565-/2005, GB/T 3566-1993, BG/T 12742, etc.

Usage: Push the sample onto the testing platform, place the rear wheel on the rear roller of the testing platform, place the front wheel on the front roller, and then quickly fix it with a cylinder (the distance between the front wheel and the wheel can be electrically adjusted). At this time, the sample can be tested without load. When the experiment

needs to be loaded, the machine applies a load and places it on the seat to fix it. The speed is adjusted by the stepper motor on the cylinder fixing claw for testing. The data is fed back to the touch screen through a transformer, current and voltage module, and control PLC for testing speed, number of turns, friction force under dry and wet conditions,

friction distance, etc.
