model

QXH-010C 020 030 050 0480

temperature range

Rt ---350 ℃

Temperature control accuracy

± 0.2 ℃

Temperature uniformity

± 2%

Box surface temperature

Not higher than 45℃

Humidity control accuracy

± 2.5%RH

Humidity uniformity

±3/-5%RH

Heating time

RT~+100℃ about 90 minutes

Inner box size

Please refer to the design drawing for related dimensions

Carton size

Please refer to the design drawing for related dimensions

Test load

3-5KW

Maximum power consumption of equipment

7.5KW

power supply

380VAC/50Hz

Controller

South Korea imported TEMI880 Chinese and English LCD touch screen programmable temperature and humidity controller

Heater

Nickel-chromium alloy electric heater

humidifier

Stainless steel sheathed humidifier (surface evaporation)

Shell material

Anti-rust treatment, cold-rolled steel plate electrostatic spray

Inner wall material

SUS304 high quality stainless steel plate

Insulation materials

Superfine glass fiber or polyurethane foam

Standard configuration

￠ One 100mm test hole cover, two shelves, four shelves, one lighting lamp (fluorescent lamp)

Optional parts

Communication interface (RS485), printer, recorder, remote monitoring computer and software, shelf, etc.

Remarks

The inner and outer dimensions are marked as: width W×height H×depth D; the cooling time is measured when the ambient temperature is 25°C without load
