1. Power supply: 220v50Hz/380v50Hz

2. Temperature range: -100℃---300℃

3. Temperature control accuracy: ±0.05%;

4. Temperature uniformity ≤0.01℃

5. Resistance measurement range, 0.001-1MΩ, accuracy 0.001mΩ

6. The tooling is suitable for installing EH/SM series terminal thermistors (see samples for details)

7. Cooling method: compressor refrigeration cooling

8. Medium: Silicone oil (-100-300℃)/alcohol

9. The lowest temperature rise rate is 0.5℃/min

10. Box body packing medium specification: 35cm*35cm

11. The software supports automatic data saving work

12. The equipment has leakage protection and undervoltage protection safety devices

13. Exportable report type data

14. Support multi-temperature point setting to automatically complete the operation (for example: 0℃-25℃-50℃-85℃-100℃-125℃-150℃)

15. The test temperature points in the automatic mode can be set at will. At least 10 temperature points can be set in a test process, and can be set from negative temperature to positive temperature, positive temperature to negative temperature, positive temperature to negative temperature and then Negative temperature and other programs.
