1. Working method: Blast internal circulation

2. Measuring temperature range: room temperature +10℃---300℃, the temperature measurement accuracy of the instrument is ±0.5℃ or 0.5%, and the resolution is 0.1℃;

3. Test station: 20 stations (multi-station test can be calculated according to customer requirements)

4. Test content: operating temperature, reset temperature, on/off life times.

5. Test rate: about 1-3 times/min;

6. Life test count: 1---999999 times can be preset

7. Control mode: PLC control, 7-inch touch screen display. With sound and light alarm function.

8. Temperature control method: K-type thermocouple, PID temperature control, dual temperature control monitoring;

9. Test current; 0-30A adjustable (optional)

10. Cooling method: automatic ventilation and exhaust.

11. Box body: aluminum + powder coating

12. Overall dimensions of the device: about 1150MM X 650MM X 1650MM (length X width X height)

13. Equipment power: 220V 5.5KW
