Vacuum cleaner motor aging test room IEC60312 GB4706.7-2014 GB_T20291.1-2014

Product Mode: Fixed mode of products: Test Speed: Number of tests: Equipment size: Description: The vacuum cleaner motor life test room is suitable for testing the life and performance of household appliances vacuum cleaner motors. Mainly for the durability life and performance test of AC and DC motors. The main components of the motor life test room are the test room body, the life test cabinet, the central control system, the exhaust system, the air inlet system, and the temperature monitoring. The entire test and monitoring inside the test room is controlled by the central control cabinet control system in real time and the test environment is monitored. The inside of the test room is composed of 3 test cabinets, which independently detect and monitor 450 vacuum cleaners. The central control system is displayed through a 21-inch display, and the entire test room is controlled by a microcomputer + mechanical control instrument. Each test frame has an alarm for abnormal products during the life and performance testing process.

Main technical parameters

1. On-off time: 0~999999 (units can be S, M, H) adjustable


2. Counting range: 0~9999999 (H) adjustable


3. Electrical parameter display: current, voltage, power,


4. Detection rate: 0.1S


5. Display mode: Numerical


6. Work alarm: abnormal voltage, current, power, end of test


7. Relevant data records: electrical parameter values, running time.


8. Control mode: 7-inch touch screen + mechanical instrument operation


9. Display: 7 inch touch type


10 Display mode: numerical display


11. Equipment power supply: AC220V /50Hz 4.5Kw
