A: High temperature resistant mesh belt structure

B: The equipment has functions such as fault alarm, counting to alarm, etc.

C: The speed of the moving parts of the equipment is adjustable, and the induction limit stops to facilitate the pick and place of the product;

Technical parameters and use environment:

1. Control method: Japan Mitsubishi PLC control

2. Control method: PLC control

3. Inspection station: 100-200 stations (according to customer order)

4. Cooling method: compressed water cooling

5. The movement speed is adjustable from 0 to 1000mm/min

6. Use place, production line equipment

7. Use ambient temperature: +5---+40℃, use ambient humidity: 20%--90%RH

8. Production beat 20S/pc

9. Power supply: 220V 50Hz 2.5KW

10. Equipment size: 750X2500X1700 Unit: mm
