A: Automatic induction of adding water, the amount of water can be controlled by time setting.

B: The equipment has functions such as fault alarm, counting to alarm, etc.

C: The speed of the moving parts of the equipment is adjustable, and the induction limit stops to facilitate the pick and place of the product;

Technical parameters and use environment:

(1), control method: Japan's Mitsubishi PLC control

(2), control mode: PLC control

(3), testing station: 100-200 stations (according to customer order)

(4) The amount of water added is adjustable from 0 to 10L/min

(5), the movement speed is adjustable from 0 to 1000mm/min, the beat: 200 per hour

(6), mechanical kettle/electronic kettle/health kettle (optional)

(7), place of use, production line equipment

(8) Ambient temperature: +5---+40℃, humidity of use environment: 20%--90%RH

(9), power supply: 220V 50HZ 3.5KW
