This equipment is a five-in-one security check electric kettle automatic water blowing station tailored according to the production site, production process and product characteristics;

Detection process

Set the relevant parameters ---- → put the electric kettle --- → the electric kettle automatically blows water (the time setting and monitoring of the test parameters can be adjusted) ---→ the electric kettle safety 5 in one test (the test can be adjusted) Parameter time setting and monitoring)--→test completed

Technical Parameters

1. Power supply: AC220, 50HZ, total power is about 10KVA

2. Control method: Japan Mitsubishi PLC control

3. Function: pressure test, leak test, electric kettle blow-dry function

4. Number of stations: 2 fixtures can test the minimum size of the kettle is 60mm, the maximum size is 200mm.

5. Timer: 1-99999 seconds, resolution; 1 second

6, 7-inch touch screen operation interface

7. Qualified and unqualified record function

8. Automatic judgment: OK—green light NG---red light

9. Weight and dimensions: about 100Kg, 800L×800W×1500H unit: mm

10. Beat: 5-7S/piece
