The technical requirements in GB4208-2008/IEC60529-2001 IP code of enclosure protection grade are IPX5, IPX6; GB/T2423.38-2005; GB/T4942.2-93 and other relevant national standards. This product is mainly suitable for waterproof performance test and IP5-IPX6 waterproof level test of electronic products, auto parts, outdoor lighting and signal devices, military industry and other products.

1. Model: QX-P5-6B

2. Nozzle diameter: φ6.3mm/φ12.5mm

3. Spray water pressure: adjust according to the prescribed water flow

4. Water spray angle: arbitrarily adjustable

5. Water spray volume: nozzle diameter 6.3mm (12.5L/min)

6. Water spray volume: nozzle diameter 12.5mm (100L/min)

7. Internal size of the storage tank: 800×800×1000: mm

8. Water pressure: displayable

9. Control method: mechanical/Mitsubishi PLC control

10. Power supply voltage: AC2200V 4.5KW

11. Equipment size: 2000 X 1200 X 1650 Unit: MM
