This set of equipment can meet the IPX1, IPX2, IPX3, and IPX4 standards specified in GB4208 IEC60529 GB7000.1 "Enclosure Protection Level"

This product is mainly suitable for waterproof performance test and IPX1234 waterproof level test of communication products, auto parts, outdoor lighting and signal devices.

PX1/2 dripping water

Drip tank size: 800×800×200; (length×width×height mm)

Precipitation: 1～5mm/min; (±0.5mm, adjustable)

Dripping area: 0.8 square meters

Drip aperture: Φ0.4mm; distance between drip holes: 20×20mm 25X25

Test bench: 500×500mm (L×W)

Test bench speed: 0-17r/min (adjustable)

PX3/4 dripping water

Swing tube swing: 0~±170° adjustable

Water jet aperture: 0.4mm or 0.8mm

Nozzle flow: 0.07L/min

Sample turntable: 1~17 /min

Spray time: 0~9999min adjustable

Control system: PLC programming control system, touch screen Chinese interface + PLC

Power supply: 220V 4.5KW

Equipment size: 1500 X 1500 X 1650 Unit: MM
