otor on-line testing equipment is mainly made according to GB/T20291 -2014, IEC60335 -2, IEC60312 and other related testing standards. Suitable for on-line comprehensive performance test before motor installation/off-line, the test parameters include voltage detection, voltage detection, current detection, input power detection, power factor, suction power, speed, flow, vacuum and efficiency. Through PLC control and monitoring, the actual simulation motor in full open/full plugging/13MM semi-plugging and other three operating conditions of the use of testing. And through the relevant vacuum, flow, voltage, current and other parameters of pre-factory pass and fail to judge. Widely used in vacuum cleaners, washing machine manufacturers for production line on-line inspection use.

Technical parameters: 1, Test Station: Unit Station 2, test items: withstand voltage test, voltage, current, power, power factor, speed, vacuum, air volume, inhalation power and efficiency. 3, control mode: Mitsubishi PLC + 17-inch Touch Screen Display 4, control interface: 17-inch touch display, with USB data export function 5, control mode: Single Point Control/multi-point linkage program control 6, even pressure box: according to the standard IEC60312(A-type design)7, valve body control mode: automatic switching 8, power supply: 220V 50Hz power 2.5 kw
