Reference Standard:

GB/T34549-2017  Sanitary ware, intelligent toilet

GB/T23131-2019  Electric toilet seats for household and similar use

GB 38448-2019 Limit of energy efficiency and water efficiency for intelligent toilet

CBMF15-2016 Smart toilet

Scope of application: experimental testing/on-line testing, such as sealing test and product durability analysis

Main technical parameters：

1.Pressure Range: 0.1 ~ 1.0 mpa adjustable

2.Pressure accuracy: ± 1% accuracy 0.25 grade

3.Constant pressure water supply time: 1-99999s

4.Pressure display: static pressure, peak value

5.Cycle Frequency: 1-20/min

6.Test period: 0-9999999 adjustable

7.Number of test: 1 Way

8.Display: curve/value

9.Test medium: normal temperature tap water

10.Driving source: frequency conversion high-pressure water pump, air pump

11.Control mode: PLC touch screen setting

12.Source: 0.6 mpa

13.Power: 220V 50HZ 6.5 kw

14.Equipment Size: 1650X750X1680MM (according to customer samples)
