According to the relevant standards, the equipment can meet the requirements of water purifier, water and other products for static pressure, water pulse and other tests, a special testing machine for pulse fatigue pressure holding test of the tested product at a maximum water pressure of 0.1-5.0 mpa. It is often used to test whether the voltage withstand test, pulse test and other tests meet the design requirements. The testing machine is controlled by FX Mitsubishi PLC/IPC, and the related tests are completed by setting and controlling the related parameters.

Main technical parameters:

1.Pressure: 1 ~ 6.5 mpa

2.Pressure driving mode: water pump frequency conversion/air pump plus-pressure booster pump

3.Pressure accuracy: 0.1 class

4.Maximum boost rate: not less than 0.2 mpa/s

5.Constant pressure time: 1-99999s

6.Cycle Pressure: 0.1-2.5 mpa settable

7.Cycle Frequency: 6-30/min

8.Cycle number: 200,000 cycles/test (settable)

9.Test number: 1 way, (maximum expansion of 5 stations)

10.Water temperature controllable range: 10 ~ 24 degrees control accuracy, plus or minus 2 degrees (optional)

11.Test medium: tap water

12.Control Screen: 7-inch, 17-inch optional (with data export function)(optional)

13.Water source: tap water, air source: not less than 0.6 mpa

14.Power: 220V 50HZ 2.5 kw
