Main technical parameters:

Pulse pressure: 1 ~ 2.5 mpa

Pressure driving mode: water pump frequency conversion/air pump pressure

Pressure accuracy: 0.1 class

Maximum boost rate: not less than 0.2 mpa/s

Constant pressure time: 1-99999s

Cycle Pressure: 0.1-2.5 mpa settable

Cycle Frequency: 6-30/min

Cycle number: 200,000 cycles/test (settable)

Test number: 1 way, (maximum expansion of 5 stations)

Water temperature controllable range: 10 ~ 24 degrees control accuracy, plus or minus 2 degrees (optional)

Test medium: tap water

Control Screen: 7-inch, 17-inch optional (with data export function)(optional)

Water source: tap water, air source: not less than 0.6 mpa

Power: 220V 50HZ 2.5 kw

Equipment Size: 1850X750X1650MM
