Vacuum cleaner performance test bench in accordance with GB/T20291.1 standard, for the vacuum cleaner air flow data test, the voltage, current, input power, power factor, suction power, flow rate, vacuum degree and efficiency of the vacuum cleaner are tested and collected. Design and manufacture according to GB/T20291.1. It can be used to measure air flow of vacuum cleaner and vacuum cleaner motor. It is widely used in various vacuum cleaner manufacturers and testing organizations. The relevant test data is exported via USB. The equipment has strong versatility, simple operation, convenient control and low failure rate.

Related technical parameters:

1.According to the national standard requirements, the national standard B 10-hole turntable flow rate test

2.500X500X500 unit: MM

3.Test pipeline: in the National Standard, the measurement accuracy of aperture conversion is ± 2% .

4.Test items: voltage, current, power, power factor, vacuum, air flow, suction power and efficiency;

5.Detection Voltage: AC/DC (10v-500v) , accuracy: 0.5%

6.Detection Current: AC/DC (0.01 a--20 a) , accuracy: 0.5%

7.Test contents: voltage, current, power, power factor, vacuum, air flow, suction power and efficiency;

8.Vacuum Manometer: (-50--0) kpa, accuracy: ± 0.5%

9.Equipment Power: 220V 50Hz 1.5 kw

10.Equipment size: 1850X680X1680 unit: MM
