Vacuum cleaner comprehensive performance test equipment, vacuum cleaner cleaning performance

 test bench is manufactured according to GB/T202911-2014 \ IEC60312-2010 IEC62885-2-2020 and

other relevant, mainly for the dust removal capability test of vacuum cleaners on carpets and floors.

The equipment is controlled by PLC, and the vacuum cleaner is driven by servo mechanism to the actual

 use conditions on the test carpet / floor for comprehensive evaluation test of vacuum cleaner dust removal capability test / cleaning capability test. The equipment drives the tested vacuum cleaner at a speed 0-1M/s through PLC related settings and control, and performs reciprocating dust removal on the test floor / carpet.

During the test, the removal performance test equipment of the vacuum cleaner, carpet dust removal,

 and hard floor dust removal capability test, the system collects relevant voltage, current, power,

electricity and other parameters, records relevant test data. Relevant test data can be exported through

 USB and printed. It is widely used for vacuum cleaner production manufacturers and testing institutions

in the cleaning industry to test the removal / cleaning ability of vacuum cleaners.

Test position: single position 2. Spreading vehicle: servo automatic ash spreading, control mode:

Japanese Mitsubishi PLC   -inch touch screen display,

 driving mode: servo stepless speed regulation 0-1.0M/S,

 effective working platform size: 600X200 unit MM, test stroke: 0-2000MM adjustable,

spreader: servo start, mechanical roller vibration , dust roller:

 diameter 5X380 fiber roller: diameter 70X380 unit: MM
